The piezo jacquard control system is the core electronic control unit for multi-bar warp knitting machines. Adopting piezoelectric ceramic driving technology, it precisely controls jacquard guide needles to produce high-density lace, elastic trims and jacquard fabrics.
• Microsecond fast response, synchronous with main shaft, stable at high running speed, reduce pattern defects.
• Low power consumption, low noise and less heat generation, longer service life compared with electromagnetic jacquard.
• Supports large repeat pattern parsing, pattern preview and fast pattern change, shorten machine setting time.
• Modular design with industrial anti-interference capability, online fault diagnosis, easy maintenance.
• Compatible with mainstream warp knitting machines, available for new machine assembly and old machine retrofitting.
Application: lace fabric, elastic lace, garment accessories, home textile jacquard, decorative mesh and technical textiles.
Technical Parameters：
| Application | Raschel and tricot machine（karl mayer,LIBA, chinese machine） |
| Input Voltage | 3-phase 380V，50/60Hz |
| Control Method | HIM and PLC |
| Support gauge | E12,E14,E16,E18,E22,E24,E26,E28,E32 |
| Driver mode | SAP8 |
| Driving voltage | 180-200V |
| Design file | KMO,MC,WKC |
| Mounting Mode | Face to face(F2F) Back to back(B2B) |
Connection method (with the control unit) | Wired and wireless control |
| Supported maximum speed | 1600RPM |
| Supported maximum width | 300 inch |
Piezo Jacquard control system
